Transolac Aluminium HR (TO 5.11)
Transolac Aluminium HR (TO 5.11) is an aluminium-based finish for interior and exterior steel surfaces, offering heat resistance up to 200°C with a silver, gloss appearance.
Transolac Aluminium HR (TO 5.11) | Heat Resistant Aluminium Finish
Transolac Aluminium HR (TO 5.11) is an aluminium-based finish designed for interior and exterior application on steel substrates where heat resistance up to 200°C is required.
The product can be applied over the Transogard priming system. For maximum temperature resistance, Transolac Aluminium HR should be applied directly to the steel substrate.
Need Product Information?
Contact BahariTech for pricing, availability and technical support.
GET A QUOTE ON WHATSAPP →Key Features of Transolac Aluminium HR
- Aluminium-based heat resistant finish
- Suitable for interior and exterior applications
- Designed for steel substrates
- Heat resistance up to 200°C
- Silver colour with a gloss appearance
- Single-component coating
Technical Specifications
| Product Code | TO 5.11 |
| Coating Type | Aluminium-Based Finish |
| Colour | Silver |
| Gloss / Appearance | Gloss |
| Volume Solids | Approx. 35% |
| Specific Gravity | Approx. 1.01 g/ml |
| VOC | Approx. 585 g/L |
| Heat Resistance | Up to 200°C |
| Recommended DFT | 30 µm per coat |
| Recommended WFT | 90 µm per coat |
| Theoretical Spreading Rate | 11.0 m²/L |
| Component | Single Component |
| Pack Size | 5 L |
Applications
Transolac Aluminium HR is suitable for interior and exterior coating applications on steel substrates where heat resistance up to 200°C is required.
Surface Preparation
Steel surfaces should be clean, dry and free from contamination. For blast-cleaned steel, the recommended surface preparation is Sa 2½ according to ISO 8501-1:2007, with a surface profile between 40 and 70 µm.
Application Methods
Transolac Aluminium HR can be applied by airless spray, airspray, brush, or roller.
Mixing and Thinning
Transolac Aluminium HR is a one-pack coating and should be thoroughly mixed with a clean mechanical mixer before application.
The recommended thinner is Transocean Alkyd Thinner 6.00. Thinning is not advised for airless spray, while 0–5% thinner may be used for airspray, brush, and roller application when required.
Curing Times
At 23°C, the product is touch dry in approximately 2 hours and dry to handle in approximately 1 day. Drying times may vary depending on film thickness, temperature, ventilation, humidity, and the preceding paint system.
Storage and Handling
Store the product in a dry, cool and well-ventilated area away from heat and ignition sources. Keep containers tightly closed and in their original packaging until required for use.
Technical Documents
For detailed technical specifications, application instructions, and product information, please refer to the available product datasheets and product documentation.
📄 | 📄 |
Frequently Asked Questions
What is Transolac Aluminium HR (TO 5.11)?
Transolac Aluminium HR is an aluminium-based finish designed for interior and exterior application on steel substrates where heat resistance up to 200°C is required.
What temperature can Transolac Aluminium HR withstand?
Transolac Aluminium HR is designed for heat resistance up to 200°C.
What colour is Transolac Aluminium HR?
The product is specified in Silver colour with a Gloss appearance.
Is Transolac Aluminium HR a single-component coating?
Yes. Transolac Aluminium HR is a one-pack coating and does not require a separate curing agent.
What surfaces can Transolac Aluminium HR be applied to?
The product is designed for application on properly prepared steel substrates.
Which thinner is recommended for Transolac Aluminium HR?
The recommended thinner is Transocean Alkyd Thinner 6.00.
| Coating Type | Aluminium-Based Finish |
|---|---|
| Pack Size | 5 L |
| Shades | TO 06 Cream (BS10B15), TO 20 Sand Yellow, TO 23 Buff (BS 358), TO 12 Signal Yellow (RAL 1021), TO 31 Sea Green (RAL 6019), TO 63 Orange (RAL 2000), TO 62 Rescue Orange, TO 64 Signal Red (RAL 3000), TO 66 Red Brown, TO 33 Eau de Nil (BS 216), TO 44 Sky Blue (RAL 5015), TO 45 Sea Blue (BS 107), TO 46 Signal Blue (RAL 5010), TO 48 Ultramarine Blue, TO 38 Green (RAL 6002), TO 53 Light Grey (RAL 7035), TO 54 Sea Grey, TO 56 Silver Grey (RAL 7001), TO 57 Deck Grey (BS 637), TO 59 Dark Grey (RAL 7012), TO 800 White, TO 899 Black |
| Finish / Appearance | Gloss |
| Component | Single Component |
| Substrate | Steel |
| Application Method | Airless Spray, Airspray, Brush, Roller |
| Recommended Thinner | Transocean Alkyd Thinner 6.00 |
